This article explains how to connect the refrigerant piping to the indoor unit for all systems.

<h2 id="introduction"><u>Introduction</u></h2><p>This article explains how to connect refrigerant piping to indoor units. The procedure for connecting the refrigerant piping to the indoor unit is the same for these systems:</p><ul><li><a href="https://www.pioneerminisplit.com/collections/diamante-essenza-high-wall-series" target="_blank" rel="noopener noreferrer">Diamante Essenza High-Wall (WYT-17)</a></li><li><a href="https://www.pioneerminisplit.com/collections/diamante-pro-high-wall-series" target="_blank" rel="noopener noreferrer">Diamante Pro High-Wall (WYT-20)</a></li><li id="isPasted"><a href="https://www.pioneerminisplit.com/collections/quantum-fresh-series-breathe-the-difference" target="_blank" rel="noopener noreferrer">Quantum Fresh High-Wall (WYT-FA)</a></li><li><a href="https://www.pioneerminisplit.com/collections/quantum-hyperformance-high-wall-series" target="_blank" rel="noopener noreferrer">Quantum Hyperformance High-Wall (WYT-25)</a></li><li><a href="https://www.pioneerminisplit.com/collections/quantum-ultra-ceiling-cassette" target="_blank" rel="noopener noreferrer">Quantum Ultra Ceiling Cassette (CYT-24)</a></li><li><a href="https://www.pioneerminisplit.com/collections/quantum-ultra-ducted-ceiling-concealed" target="_blank" rel="noopener noreferrer">Quantum Ultra Ducted Ceiling Concealed (RYT-24)</a></li><li><a href="https://www.pioneerminisplit.com/collections/quantum-ultra-universal-flex-series" target="_blank" rel="noopener noreferrer">Quantum Ultra Floor-Ceiling Flex (UYT-24)</a></li><li id="isPasted"><a href="https://www.pioneerminisplit.com/collections/quantum-ultra-high-wall-series" target="_blank" rel="noopener noreferrer">Quantum Ultra High-Wall (WYT-24)</a></li></ul><h2 id="steps"><u>Steps</u></h2><ol><li>Unwind the copper piping kit.&#xA0;</li><li>Bring the ends of both the copper line and the indoor unit line together. Align the centers of the pipes that will be connected.&#xA0;</li><li>Remove the indoor unit piping cap and check that no debris is inside. Some gas may be heard escaping, but it is dry nitrogen keeping the lines clean.&#xA0;</li><li>Use leak guards and/or flare sealers on the flares of the piping.&#xA0;<img src="https://attachments.gorgias.help/Q9r0k7BYaV2vg13y/hc/9JWjXVxG8m6DvMqm/2025120121-5bc63465-9834-475f-bb23-4022b918061b-wyt17_connect_refrigerant_piping_idu_leak_guard.png" style="width: 500px;" class="fr-fic fr-dib fr-bordered"></li><li>Attach the flare nut and tighten as much as possible by hand.&#xA0;<img src="https://attachments.gorgias.help/Q9r0k7BYaV2vg13y/hc/9JWjXVxG8m6DvMqm/2025120121-204b8ed5-e815-4959-a3a0-74df9a2d8c47-wyt17_connect_refrigerant_piping_hand_tighten.png" style="width: 500px;" class="fr-fic fr-dib fr-bordered"></li><li>Use two wrenches to torque correctly to the specifications found in the table below.<img src="https://attachments.gorgias.help/Q9r0k7BYaV2vg13y/hc/9JWjXVxG8m6DvMqm/2025120121-44bc1f73-4a86-4f7f-934a-d95216d830e5-wyt17_connect_refrigerant_piping_torque_wrench.png" style="width: 500px;" class="fr-fic fr-dib fr-bordered"></li><li>Repeat this process for the other copper line.&#xA0;</li></ol><h2 id="tightening-torque-for-protection-caps--flange-connection"><u>Tightening Torque for Protection Caps &amp; Flange Connection</u></h2><table style="width: 100%;"><thead><tr><th class="fr-thick"><div style="text-align: center;">Pipe Diameter</div></th><th style="text-align: center;" class="fr-thick">Tightening Torque<br>[N x m]</th><th style="text-align: center;" class="fr-thick">Tightening Torque<br>[ft-lbf]</th><th style="text-align: center;" class="fr-thick">Corresponding Stress<br>(Using a 20 cm wrench)</th></tr></thead><tbody><tr><td style="width: 25.0000%;" class="fr-thick"><div style="text-align: center;">&#x3A6; 1/4&quot; (6.35 mm)</div></td><td style="width: 25%; text-align: center;" class="fr-thick">15-20</td><td style="width: 25%; text-align: center;" class="fr-thick">11-15</td><td style="width: 25%; text-align: center;" class="fr-thick">Wrist strength</td></tr><tr><td style="width: 25%; text-align: center;" class="fr-thick">&#x3A6; 3/8&quot; (9.52 mm)</td><td style="width: 25%; text-align: center;" class="fr-thick">31-35</td><td style="width: 25%; text-align: center;" class="fr-thick">23-26</td><td style="width: 25%; text-align: center;" class="fr-thick">Arm strength</td></tr><tr><td style="width: 25%; text-align: center;" class="fr-thick">&#x3A6; 1/2&quot; (12 mm)</td><td style="width: 25%; text-align: center;" class="fr-thick">45-50</td><td style="width: 25%; text-align: center;" class="fr-thick">33-37</td><td style="width: 25%; text-align: center;" class="fr-thick">Arm strength</td></tr><tr><td style="width: 25%; text-align: center;" class="fr-thick">&#x3A6; 5/8&quot; (15.88 mm)</td><td style="width: 25%; text-align: center;" class="fr-thick">60-65</td><td style="width: 25%; text-align: center;" class="fr-thick">44-48</td><td style="width: 25%; text-align: center;" class="fr-thick">Arm strength</td></tr></tbody></table><p><br></p><table style="width: 58%; margin-right: calc(42%);"><thead><tr><th colspan="2" style="width: 100%;" class="fr-thick"><div style="text-align: center;">Tightening Torque [N x m] (ft-lbf)</div></th></tr></thead><tbody><tr><td style="width: 50%; text-align: center;" class="fr-thick">Service Port Nut</td><td style="width: 50%; text-align: center;" class="fr-thick">[7-9] (5-7)</td></tr><tr><td style="width: 50%; text-align: center;" class="fr-thick">Protection Caps</td><td style="width: 50%; text-align: center;" class="fr-thick">[25-30] (18-22)</td></tr></tbody></table>

Connect the Refrigerant Piping to the Indoor Unit
