<h2 id="introduction"><u>Introduction</u></h2><p>The <a href="https://www.pioneerminisplit.com/collections/quantum-ultra-high-wall-series" target="_blank" rel="noopener noreferrer">Quantum Ultra - High-Wall series (WYT-24)</a> is a ductless wall-mounted mini split systems with various capacities and efficiency ratings, making them easy to install and providing reliable single-zone comfort. The Quantum Ultra - High-Wall series is factory-precharged with environmentally-friendly R454B refrigerant.&#xA0;</p><p>The mini split comes with a convenient remote controller that conveys cooling, heating, dehumidification, and ventilation requests. The automatic air-sweeping louvers, automatically varying air flow, and capacity adjustments keep the zone at the ultimate comfort level.</p><p>For more information, see this <a href="https://www.pdhvac.com/site/dl/wyt24/WYT24-BROC-2501.pdf" target="_blank" rel="noopener noreferrer">technical brochure</a>.&#xA0;</p><h2 id="indoor-units"><u>Indoor Units</u></h2><ul><li>WT009ALSI24HLG</li><li>WT012ALSI24HLG</li><li>WT009GLSI24HLG</li><li>WT012GLSI24HLG</li><li>WT018GLSI24HLG</li><li>WT024GLSI24HLG</li></ul><h2 id="outdoor-units"><u>Outdoor Units</u></h2><ul><li>YN009ALSI24RPG</li><li>YN012ALSI24RPG</li><li>YN009GLSI24RPG</li><li>YN012GLSI24RPG</li><li>YN018GLSI24RPG</li><li>YN024GLSI24RPG</li></ul>

The Quantum Ultra - High-Wall series is a ductless wall-mounted mini split systems with various capacities and efficiency ratings.

Quantum Ultra - High-Wall Series (WYT-24) Overview
