These codes indicate fan-related faults involving either the outdoor fan&#x2019;s DC bus voltage or communication with the indoor fan module.&#xA0;<ul><li style="font-size: 16px;">EH3A Error Code:&#xA0;Outdoor unit fan DC bus undervoltage protection.&#xA0;</li><li style="font-size: 16px;">EH3b Error Code:&#xA0;Outdoor unit fan DC bus overvoltage protection.&#xA0;</li><li style="font-size: 16px;">EHbA Error Code:&#xA0;Communication error between the indoor unit and indoor fan module.</li></ul>The indoor unit does not receive feedback from the external fan module for 150 seconds, or the indoor unit receives abnormal increases or decreases in voltage from the external fan module.&#xA0;Recommended Part to Prepare<ul><li style="font-size: 16px;">Indoor unit PCB</li></ul><img src="https://attachments.gorgias.help/Q9r0k7BYaV2vg13y/hc/9JWjXVxG8m6DvMqm/2026101414-b822dc7c-d370-4692-a18c-b796729e2cbe-eh3a_eh3b_ehba_code.png" style="width: 600px;" class="fr-fic fr-dib fr-bordered">

These codes indicate fan-related faults involving either the outdoor fan’s DC bus voltage or communication with the indoor fan module.

EH3A, EH3b, and EHbA Error Codes
